PROTOTYPE W27
PROTOTYPE W27
The SIMS PROTOTYPE blends advanced engineering with refined geometry for riders seeking top-tier performance across varied terrain. With a twin sidecut, set-back stance, and an extended nose, this board delivers balanced versatility and confident float in deep snow while maintaining precision control on groomers.
Shape
Directional
Traditional Camber
A single convex arc between the board’s contact points ensures predictable edge hold, load, and rebound as pressure is exerted and expelled throughout the rider’s turn.
MOD 3 Core
A combination of poplar wood native to North America
and high strength to weight ratio bamboo provides
propulsive performance in this Core. We increased the
width of the bamboo array to increase the strength and
energized feel of this Co
Tri-Tex Fiberglass
Our most advanced matrix is a 3-way layup that combines Light fiberglass at 0º, 45º, and 90º degrees, ensuring unquestionable pop, rebound, flex, and torsion in our highest performance boards.
I Carbon Stringer
A 50 mm carbon stringer provides lightweight rigidity to improve pop and power in all environments.
Premium Racing Base
This base utilizes a sintered high-density, high-speed base material chosen for its molecular weight, which delivers unrivaled speed, excellent wear resistance, and increased wax permeability.
Sizes
146, 152, 156.5, 159.5
Tech Specs
The PROTOTYPE rides on SIMS MOD 3 construction—a combination of poplar wood with thin bands of bamboo running along the edges for increased edge hold and stability at speed. SIMS Twin Wave Form technology advances core construction further by thickening the core under the binding hole patterns, resulting in greater shock absorption and quicker edge-to-edge response from the slight increase in leverage.
We run a 50mm strip of I Carbon through the PROTOTYPE to increase power and pop while delivering smooth rebound out of the turn. Tri-Tex fiberglass, SIMS’s most advanced high-end matrix, adds responsive strength and long-lasting durability. The PROTOTYPE finishes it off with our high-density, high-speed Premium Racing Base.
Spec |
146 |
152 |
156.5 |
159.5 |
RUNNING LENGTH (MM) |
1040 |
1060 |
1060 |
1060 |
EFFECTIVE EDGE (MM) |
1075 |
1095 |
1130 |
1155 |
NOSE/TAIL WIDTH (MM) |
290/280 |
300/290 |
298.5/294.5 |
310/300 |
NOSE/TAIL LENGTH (MM) |
280/140 |
300/160 |
300/205 |
370/165 |
WAIST WIDTH (MM) |
248 |
257 |
257 |
266 |
STANCE RANGE (MM) |
380-580 |
420-620 |
420-620 |
460-660 |
SET BACK (MM) |
0 |
0 |
0 |
0 |
SIDECUT RADIUS (M) |
7.2 |
7.3 |
7.4 |
7.9 |
CAMBER PROFILE
Traditional Camber
A single convex arc between the board’s contact points ensures predictable edge hold, load, and rebound as pressure is exerted and expelled throughout the rider’s turn.
WOOD CORE
MOD 3
A combination of poplar wood native to North America
and high strength to weight ratio bamboo provides
propulsive performance in this Core. We increased the
width of the bamboo array to increase the strength and
energized feel of this Core.
CORE PROFILE
Twin Wave Form
This proprietary design adds depth and dimension to
the wood core beneath the feet for focused drive, flex,
and cont
BASE
Premium Racing
This base utilizes a high-density, high-speed base material chosen for its molecular weight, which delivers unrivaled speed, excellent wear resistance, and increased wax permeability.
TIP TECHNOLOGY
Regular Tip
A traditional construction that features full wood core
content from tip-to-tail for smooth-flexing stability and
durability.
FIBERGLASS LAMINATE
Tri-Tex
This is our most advanced matrix; a 3-way lay up that combines Light fiberglass at 0º, 45º, and 90º degrees, ensuring unquestionable pop, rebound, flex, and torsion in our highest performance boards.
CARBON LAY-UP
I Carbon
A 50 mm carbon stringer provides lightweight rigidity to
improve pop and power in all environments.
